Standard Duty Left-Hand Offset Bracket Wall Mount Shower Door Pivot Hinge

PRODUCTS

Classification

SHOWER FITTING

Standard Duty Left-Hand Offset Bracket Wall Mount Shower Door Pivot Hinge

Products Code:
PSH-P12
Cardiff Series Hinges
Standard Duty Shower Door Pivot Hinge with Straight Edge and Straight Corner
零售价
0.0
Yuan
[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[市场价, 市场价]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]
0.0
Yuan
浏览量:
1000
数量
-
+
库存:
暂时无货
1
Product Details
[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[[产品参数, 参数]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]]

Standard Duty Left-Hand Offset Bracket Wall Mount Shower Door Pivot Hinge

Products Code:
PSH-P12



Prodiamonds' Standard Duty Left-Hand Offset Bracket Wall Mount Shower Door Pivot Hinge with Straight Edge Straight Corner are similar to PSH-P30 Series Shower Door Pivot Hinge with Beveled Edge Round Corner.



Advantages of the above two series of Pivot Hinges include the fact that they carry the majority of the weight on the bottom, and have the ability to be inset from the wall, enabling clearance for towel bars and other projections. The Glass-to-Fixed Transom Mount Pivot Hinge is used for doors having fixed transoms above them. When placed vertically, either style can be used in movable transom installations. These Pivot Hinges are self-centering, with four springs for maximum retention strength.

The P11 Model is adaptable to our Deluxe Header System. The P15 Model is only compatible with our EZ-Adjust Header System. It includes an adaptor used with our EZ-Adjust Header System.





Material: Solid Brass

Glass Thickness: 5/16" (8mm) or 3/8" (10mm)

Hinge Width: 3-5/8" (92 mm)

Hinge Swing: Full Rotation

Closing Type: Self-Centering when within 15° of closed position

Finishes: Chrome, Brushed Nickel, Matte Black, PVD Gold, etc.



Using two hinges hold up to 100 lbs/45 kg with a max. width of 31"/787 mm

Can be mounted floor and ceiling, or floor and header using the standard adapter block

Standard Duty Left-Hand Offset Bracket Wall Mount Shower Door Pivot Hinge

扫二维码用手机看
未找到相应参数组,请于后台属性模板中添加
Hot fag:
Offset Bracket Wall Mount Pivot Hinge
glass shower door pivot hinge
bath screen pivot hinges
